Configuring traffic mirroring and traffic redirecting

for a traffic behavior

1. Select QoS > Behavior from the navigation tree.

2. Click Port Setup to enter the port setup page for a traffic behavior.

Figure 466 Port setup page for a traffic behavior

3. Configure traffic mirroring and traffic redirecting as described in Table 154.

4. Click Apply.

Table 154 Configuration items

Item Descri

tion

Please select a behavior

Select an existing behavior in the list.

Mirror To

Set the action of mirroring traffic to the specified destination port.

Redirect

Set the action of redirecting traffic to the specified destination port.

Please select a port

Specify the port to be configured as the destination port of traffic mirroring or

traffic directing on the chassis front panel.

Configuring other actions for a traffic behavior

1. Select QoS > Behavior from the navigation tree.

2. Click Setup to enter the page for setting a traffic behavior.
