100
Configuring an alarm entry
1. Select Device > RMON from the navigation tree.
2. Click the Alarm tab.
Figure 86 Alarm entry
3. Click Add.
Figure 87 Adding an alarm entry
4. Configure an alarm entry as described in Table 27.
5. Click Apply.
Table 27 Configuration items
Item Descri
p
tion
Alarm variable:
Static Item
Set the traffic statistics that are collected and monitored. For
more information, see Table 28.
Interface Name
Set the name of the interface whose traffic statistics are
collected and monitored.
Sample Item:
