270
Ste
p
Remarks
2. Configuring MLD snooping in
a VLAN
Required.
Enable MLD snooping in the VLAN and configure the MLD snooping
version and querier.
By default, MLD snooping is disabled in a VLAN.
When you enable MLD snooping, follow these guidelines:
• Enable MLD snooping globally before you enable it for a VLAN.
• MLD snooping for a VLAN takes effect only on the member ports in
that VLAN.
3. Configuring MLD snooping
port functions
Optional.
Configure the maximum number of IPv6 multicast groups and fast-leave
processing on a port of the specified VLAN.
When you configure MLD snooping port functions, follow these
guidelines:
• Enable MLD snooping globally before you enable it on a port.
• MLD snooping enabled on a port takes effect only after MLD
snooping is enabled for the VLAN.
4. Displaying MLD snooping
multicast forwarding entries
Optional.
Enabling MLD snooping globally
1. Select Network > MLD snooping from the navigation tree.
2. Click Enable for MLD snooping.
3. Click Apply.
Figure 243 Enabling MLD snooping globally
Configuring MLD snooping in a VLAN
1. Select Network > MLD snooping from the navigation tree.
