99
Configuring an event entry
1. Select Device > RMON from the navigation tree.
2. Click the Event tab.
Figure 84 Event entry
3. Click Add.
Figure 85 Adding an event entry
4. Configure an event entry as described in Table 26.
5. Click Apply.
Table 26 Configuration items
Item Descri
p
tion
Description Set the description for the event.
Owner Set the entry owner.
Event Type
Set the actions that the system takes when the event is triggered:
• Log—The system logs the event.
• Trap—The system sends a trap in the community name of null.
If you select both Log and Trap, the system logs the event and sends a trap. If
neither is selected, the system takes no action.
