223
Ste
p
Remarks
5. Displaying global LLDP
information.
Optional.
You can display the local global LLDP information and statistics.
6. Displaying LLDP
information received
from LLDP neighbors.
Optional.
You can display the LLDP information received from LLDP neighbors.
Enabling LLDP on ports
1. From the navigation tree, select Network > LLDP.
By default, the Port Setup tab is displayed. This tab displays the enabling status and operating
mode of LLDP on a port.
2. Select one or more ports and click Enable.
To disable LLDP on a port, select the port and click Disable.
Figure 198 The port setup tab
