Item Descri

tion

Select ports to be

modified and

assigned to this VLAN

Select the ports to be modified in the selected VLAN.

When you configure an access port as a tagged member of a VLAN, the link type of the

port is automatically changed into hybrid.

Modifying ports

1. From the navigation tree, select Network > VLAN.

2. Click Modify Port to enter the page for modifying ports.

Figure 139 Modifying ports

3. Modify the VLANs of a port as described in Table 42.

4. Click Apply.

A progress dialog box appears.

5. Click Close on the progress dialog box when the dialog box prompts that the configuration

succeeds.

Table 42 Configuration items

Item Descri

tion

Select Ports

Select the ports to be modified.
