C100_110-160_180.FB 10 Tue Jul 16 06:36:50 1996

Removing Option Boards

NOTICE: Any option boards that are supported by the new C160/180 system should

be installed in the same slot number in the new main tray.

If your C100/110 system has any option boards installed, you must remove

them from the original C100/110 main tray, as described in the following

procedure:

1 Press the fan release clip and rotate the fan, as shown in Figure 5.

Figure 5 Rotating the Fan
